In the competitive landscape of educational toys and STEM learning products, brand differentiation is essential. Off-the-shelf catalog items are often subject to intense price competition across marketplaces like Amazon, Walmart, and specialty retail stores. To build lasting brand equity, distributors and toy brands invest in custom OEM (Original Equipment Manufacturing) and ODM (Original Design Manufacturing) solutions.
Developing a custom educational toy requires balancing aesthetic design with mechanical function, safety limits, and cost constraints. At Lione Toys, we guide global clients through every step of this process—from initial sketch concepts to final, certified retail products.
+-----------------------------------------------------------------------------------+
| LIONE TOYS OEM/ODM WORKFLOW PIPELINE |
| |
| [ PHASE 1 ] Engineering CAD & 3D Prototyping |
| │ |
| ▼ |
| [ PHASE 2 ] Precision Tooling & Steel Mold Fabrication |
| │ |
| ▼ |
| [ PHASE 3 ] Pre-Production Testing & Certification Compliance |
| │ |
| ▼ |
| [ PHASE 4 ] Mass Production, Automated Assembly & Quality Audits |
| │ |
| ▼ |
| [ PHASE 5 ] Custom Packaging, Warehousing & Global Logistics |
+-----------------------------------------------------------------------------------+
1. Phase 1: Product Design, Engineering & 3D Prototyping
Every successful OEM project starts with precise technical planning. Whether you present a rough concept sketch or complete 3D mechanical drawings, our engineering team evaluates structural durability, wall thickness tolerances, and material physics.
[ Client Concept / Sketch ]
│
▼
[ 3D CAD Modeling (STEP/IGS) ] ──► Mold Flow Analysis
│
▼
[ Functional SLA/SLS Prototyping ] ──► Physical Hand Sample Inspection
Mechanical Considerations for Magnetic Tiles
- Magnet Placement & Flux Balance: Internal magnet pockets are calculated to prevent internal rattling while maintaining correct magnetic alignment and force.
- Ribbing Structure: Internal cross-ribbing prevents plastic distortion during injection molding and adds flexural strength under load.
Board Game Component Engineering
- Custom Token & Pawn Geometry: Custom plastic player tokens are designed with draft angles to allow smooth ejection from injection molds.
- Card Deck & Tile Specs: Paper weights, card coatings, and chipboard thicknesses are selected to withstand repeated handling.
2. Phase 2: Tooling & Mold Fabrication
Once 3D prototypes are approved, engineering moves to steel mold development. Tooling quality directly determines finished part surface finish, seam tightness, and cycle time efficiency.
+-----------------------------------------------------------------------+
| STEEL MOLD FABRICATION METRICS |
+-----------------------------------+-----------------------------------+
| Steel Grade | NAK80 / P20 High-Hardness Steel |
+-----------------------------------+-----------------------------------+
| Mold Life Expectancy | 500,000+ Shot Cycles |
+-----------------------------------+-----------------------------------+
| Cavity Configuration | Multi-Cavity (High Output) |
+-----------------------------------+-----------------------------------+
| Surface Treatment | High-Gloss Polish / Texture Etch |
+-----------------------------------+-----------------------------------+
During mold cutting, our engineers run Mold Flow Analyses to identify potential air traps, weld lines, or sink marks. Correcting these factors in the tooling design stage ensures consistent part quality across multi-thousand unit runs.
3. Phase 3: Pre-Production Sampling & Safety Certification
Before mass production begins, golden pre-production samples are produced and submitted for physical, chemical, and functional testing.
+----------------------------------+
| PRE-PRODUCTION GOLDEN SAMPLE |
+-----------------+----------------+
|
+----------------------------+----------------------------+
| | |
[ PHYSICAL TESTING ] [ CHEMICAL ANALYSIS ] [ PACKAGING DROP AUDITS ]
• Drop-Impact Tests • Heavy Metals (EN71-3) • ISTA-1A Transit Test
• Magnet Pull Force • Phthalate Screen • Box Compression
• Tension / Torque • CPSIA Lead Limits • Retail Shelf Display
- Lab Submission: Samples are sent to accredited testing labs (SGS, TÜV, Intertek) to secure official test reports (ASTM F963, EN71, CPC) required for import customs clearing.
- Client Validation: The client receives physical golden samples to confirm color accuracy, magnetic force, surface finish, and print quality.
4. Phase 4: Mass Production & Automated Assembly
Upon golden sample approval, mass manufacturing begins. Lione Toys operates dedicated injection molding workshops, ultrasonic welding stations, and assembly lines.
Raw Resin Loading ──► Injection Molding ──► Ultrasonic Magnet Sealing ──► Structural Inspection
│
Shrink-Wrapping ◄── Packaging Kitting ◄── Automated Weighing Station ◄──────┘
- Automated Injection: Plastic resin is dried, mixed with masterbatch colorants, and injected under precise pressure and temperature conditions.
- Ultrasonic Magnet Insertion: Magnets are robotically or manually positioned into housing cavities before high-frequency ultrasonic welding seals the shells shut.
- Inline Quality Checks: Operators test joint strength and inspect clarity on a regular sampling schedule.
5. Phase 5: Packaging & Customized Branding
Retail success depends heavily on structural and visual packaging execution. We support custom packaging styles tailored to your target distribution channels:
+-----------------------------------------------------------------------------+
| CUSTOM PACKAGING OPTIONS |
+-------------------------+-------------------------+-------------------------+
| Window Gift Boxes | Rigid Setup Boxes | Storage Plastic Tubs |
| • PET Clear Windows | • Heavyweight Chipboard | • Stackable Design |
| • Corrugated Inserts | • Magnetic Closures | • Molded Handles |
| • Gloss/Matt Lamination | • Premium Linen Texture | • In-Mold Label Printing|
+-------------------------+-------------------------+-------------------------+
- Amazon FBA Ready: Custom barcodes (FNSKU), master carton labeling, Suffocation Warning polybags, and drop-test reinforced outer cartons.
- Retail Shelf Ready: Bright, high-resolution CMYK color printing, spot UV highlights, foil stamping, and custom internal tray organizers.
6. Frequently Asked Questions (FAQ)
Q: Who owns the intellectual property (IP) and injection molds for custom OEM orders?
A: The client retains 100% ownership of all custom tooling, CAD designs, and artwork paid for during development. Molds are held at our facility under strict non-disclosure agreements (NDAs) and are never used for third-party production.
Q: What is the typical cost for custom mold creation?
A: Tooling costs vary based on component dimensions and cavity count. A simple single-part mold starts around $1,500–$3,000, while complex multi-part magnetic building sets or detailed board game components range from $5,000 to $15,000+.
Q: Can Lione Toys assist with artwork and graphic layout for board game components?
A: Yes. Our internal design team can adapt your raw illustrations and game concepts into production-ready die-line templates for card decks, game boards, spinner boards, and retail boxes.
Q: How are small game parts packaged to prevent loss during shipping?
A: Small components—such as dice, tokens, or magnetic accessories—are heat-sealed in transparent polybags or secured within custom thermoformed inner trays to ensure complete box contents upon delivery.
Turn Your Product Concepts into Reality
Developing a high-margin custom educational product requires a structured manufacturing pipeline. Lione Toys offers the engineering depth, production scale, and quality systems needed to launch your next product line safely and efficiently.
